The AVAGO HFBR-4503 CONNECTOR AND CABLE ASSEMBLY AND POLISHING simplex latching plug offers robust performance for applications requiring high retention force. The plug is suitable for use with 2.2 mm plastic optical fiber (POF).
The latching mechanism provides a securely mated fit once inserted into a RedLink® connector. Applying pressure to the rear of the plug releases the latching mechanism. This allow for easy removal of the plug from the connector. The simplex latching plug is available in both grey and blue colours.
Specifications
|
Plug Specifications |
|||||
|
Parameter |
Symbol |
Min |
Typical |
Max |
Unit |
|
Storage Temperature |
Tstg |
-40 |
+85 |
°C |
|
|
Operating Temperature |
Top |
-40 |
+85 |
°C |
|
|
Installation Temperature |
TI |
0 |
+70 |
°C |
|
|
Retention Force,Connector to Transceiver |
FR |
47 |
N |
||
|
Retention Force,Connector to Transceiver |
FR |
11 |
N |
||
|
Insertion Force,Connector to Transceiver |
FR |
35 |
N |
||
|
Durability,Mating Cycles |
500 |
||||
|
Fixing Method |
Crimp |
||||

Connector And Cable Assembly And Polishing
- FIGURE 1. Jacket Strip Length
- FIGURE 2. Jacket Stripper on POF cutter
- FIGURE 3. Cable and Connector Positioning
- FIGURE 4. Secure Simplex Connector
- FIGURE 5. Polishing Disc

Features
1.RoHS-Compliant
2.Compatible with Broadcom Versatile Link family of connectors and fiber optic components
3.1 mm diameter Plastic Optical Fiber (POF) in two grades: low cost standard POF with 0.22 dB/m typical attenuation, or high performance extra low loss POF with0.19 dB/m typical attenuation
Application
- Industrial automation control bus system
- Industrial robot intelligent system and servo system
- Communication switching system
- Digital multimedia system
- Medical sensing system
- Power system
