Products Description
Fiber patch cables provide interconnect and cross-connect of applications over installations in entrance facilities,telecommunications rooms, data cent res, and at the desk.This G657A1 fibre patch cable is ideal for connecting 1G/10G/25G/40G/100G/400G Ethernet connections. It is best suited for long distance application and can transport data for up to 10km at 1310nm, or up to 40km at 1550nm.
The bend insensitive fibre patch cable has less attenuation when bent or twisted compared with traditional fibre patch cable and this will make the installation and maintenance more efficient.
Product Paramenters
|
MODEL NO |
Fiber Optic Patch Cord |
|
Fiber Type |
SM ( G652 / G657A1 / G657A2 ) |
|
Cable Assembilies |
Simplex |
|
Jacket Material |
PVC / LSZH |
|
Cable Diameter (mm) |
2.0 / 3.0 |
|
Connector Type |
SC / LC |
|
End Face |
UPC / APC |
|
Working Wavelength (nm) |
1310/1550 |
|
Insertion Loss (dB) |
≤0.3dB(MAX) ≤0.2dB(Typical) |
|
Return Loss (dB) |
UPC ≥55dB APC ≥60dB |
|
Exchangeability |
≤0.2dB |
|
Operating Temperature(℃) |
-40~85 |
Key Features
Low Insertion Loss, High Return Loss
Available in Single-Mode and Multi-Mode
Connector Options: LC, SC, FC, ST, MU, MPO, MTP
Custom Lengths and Jacket Materials (PVC/LSZH/OFNP)
100% Factory Tested for Performance & Durability
Complies with IEC, TIA/EIA, ISO/IEC Standards
RoHS & CE Certified
Applications
Data Centers & Cloud Infrastructure
FTTH (Fiber to the Home) Networks
Optical Distribution Frames (ODFs)
CATV and CCTV Systems
Telecom Equipment Interconnection
High-Speed LAN/WAN Networks
COMPANY INFORMATION
Yangzhou RSPOF Technology Co., Ltd. is a high-tech enterprise integrating independent R&D, design, production, and sales of POF plastic optical fiber cable products. Our current product series includes plastic optical fiber cables, data communication jumpers, AVAGO cables, MOST cables, Lighting fibers, and peripheral connecting lines etc. Our products take the lead roles in the POF application fields of data transmission, industrial control, power control, industrial automation, automobile intelligence, etc. In the process of development, our company has passed "ISO9001", "CE", and " ROHS" professional certifications.
We are committed to the construction of a talented Team. Always adhere to people-oriented. Win-win cooperation with our cooperation partners. Determined to provide global customers with high-quality, reasonable prices, and life-long after-sales service products. In future development, we will focus on customer demands, constant innovation, and seek long-term cooperation with partners. We would stand on solid ground and keep improving. Become a world-leading brand technology manufacturer in the market.
PACKAGING & SHIPPING
