Products Description
OD: 1.0*2.2*6.0mm Single-core Plastic Optical Fiber is a high-performance optical fiber available in both simplex and duplex types. This fiber features a high-purity 1 mm PMMA core and a specially selected transparent polymer cladding. The core and cladding are encased in a 2.2 mm polyethylene (PE) sheath and a 6.0 mm polyvinyl chloride (PVC) sheath. is a high-performance optical fiber available in both simplex and duplex types. This fiber features a high-purity 1 mm PMMA core and a specially selected transparent polymer cladding. The core and cladding are encased in a 2.2 mm polyethylene (PE) sheath and a 6.0 mm polyvinyl chloride (PVC) sheath.
Basic Information
OD: 1.0*2.2*6.0mm
Material: PMMA/ PE/PVC
Number of fiber :1
Minimum Bend Radius:25mm
Transmission Loss: ≤ 200dB/km @650nm
Numerical Aperture: 0.5NA
Core Refractive Index:1.49
Temperature Range:-55°C to +70°C
Customization: customized logo on the cable
RoHS/REACH Compliant
Features
OD: 1.0*2.2*6.0mm Single-core Plastic Optical Fiber is encased in a PE sheath, with PVC or other sheath materials serving as a second sheath over the POF. This structure provides superior resistance to compression, tension, abrasion, and aging, thus extending its service life. This sheath is suitable for multiple applications. The unique tight-fitting structure within the cable makes it difficult to bend during processing or use, while also allowing for easy stripping of small amounts of sheath. Our plastic optical cables offer advantages such as high transmission bandwidth, resistance to electromagnetic interference, and stable signal transmission.
If you have a special application and can not find a cable of the appropriate specification on our web page, please send us an email (Info@rspof.com), we will contact you and provide a quotation for your customized POF cable.
Shipment
Hot Tags: od: 1.0*2.2*6.0mm single-core plastic optical fiber, China od: 1.0*2.2*6.0mm single-core plastic optical fiber manufacturers, suppliers, factory
