Mitsubishi ESKA high-quality Plastic Optical Fiber
Hecho is an authorized reseller of Mitsubishi Rayon optical fiber. Our company maintains full inventories of Mitsubishi Rayon Eska™, Super Eska™, Eska™ Premier and Eska™ Mega PMMA optical fiber and fiber cable.
Our lighting grade PMMA plastic optical fiber, from bare fiber to single-core optical fiber cable, from multi-core to stranded Fiber Optic Cable, a free combination of different products to meet a variety of fiber optic lighting applications.
PMMA bare fiber core diameter range 0.25mm-3.0mm, soft, high light rate for the stars, fiber bundles, toy decoration, fiber optic lights, fiber optic curtains and other lighting applications.
Unjacketed Fiber Cable
|
Model |
Fiber Dia.(mm) |
Loss (dB/km) |
Tensile strength (N) |
N.W.(kg) |
G.W.(kg) |
Storage tem(℃) |
Packing |
|
CK-10 |
0.25 |
400 |
3 |
0.72 |
1.7 |
-55～+70 |
12000 |
|
CK-20 |
0.5 |
350 |
14 |
1.44 |
2.7 |
-55～+70 |
6000 |
|
CK-30 |
0.75 |
300 |
35 |
1.45 |
2.7 |
-55～+70 |
2700 |
|
CK-40 |
1 |
300 |
65 |
1.5 |
2.8 |
-55～+70 |
1500 |
|
CK-60 |
1.5 |
300 |
126 |
1.54 |
2.8 |
-55～+70 |
700 |
|
CK-80 |
2 |
300 |
224 |
0.95 |
1.7 |
-55～+70 |
350 |
|
CK-100 |
2.5 |
300 |
350 |
1.5 |
2.2 |
-55～+70 |
250 |
|
CK-120 |
3 |
300 |
504 |
1.29 |
2 |
-55～+70 |
150 |
Jacketed Fiber Optic Cable
|
Model |
Core Dia./QTY |
O.D. |
Packing |
Outter Materials |
Loss (dB/km) |
|
SH1001 |
0.25mm×1 |
1.0±0.05 |
1000 |
PE |
700 |
|
SH2001 |
0.5mm×1 |
1.0±0.05 |
1000 |
PE |
210 |
|
SH2002 |
0.5mm×2 |
1.0×2.0±0.1 |
500 |
PE |
210 |
|
SH3001 |
0.75mm×1 |
2.2±0.07 |
500 |
PE |
200 |
|
SH3002 |
0.75mm×2 |
2.2×4.3±0.1 |
500 |
PE |
200 |
|
SH4001 |
1.0mm×1 |
2.2±0.07 |
1000 |
PE |
190 |
|
SH4002 |
1.0mm×2 |
2.2×4.3±0.1 |
500 |
PE |
190 |
|
SH6001 |
1.5mm×1 |
3.0±0.15 |
500 |
PE |
190 |
|
SH8001 |
2.0mm×1 |
3.0±0.15 |
500 |
PE |
200 |
|
SHV4001 |
1.0mm×1 |
2.2±0.07 |
500 |
PVC |
190 |
|
SHEV4001 |
1.0mm×1 |
4.0±0.2 |
500 |
PE/PVC |
200 |
|
SHCP4001 |
1.0mm×1 |
2.2±0.07 |
500 |
CHLORINATED |
200 |
|
SHCP4002 |
1.0mm×2 |
2.2×4.3±0.1 |
500 |
PE |
200 |
|
SH-1004 |
0.25mm×4 |
1.0±0.05 |
1000 |
PE |
650 |
|
SH-1009 |
0.25mm×9 |
1.3±0.05 |
500 |
PE |
650 |
|
SH-1010 |
0.25mm×10 |
1.3±0.05 |
500 |
PE |
650 |
|
SH1016 |
0.25mm×16 |
2.2±0.07 |
500 |
PE |
650 |
|
SH1032 |
0.25mm×32 |
2.8±0.07 |
500 |
PE |
650 |
|
SH1048 |
0.25mm×48 |
3.0±0.07 |
500 |
PE |
650 |
|
SH1064 |
0.25mm×64 |
3.25±0.07 |
500 |
PE |
650 |
|
GH4001 |
1.0mm×1 |
2.2±0.07 |
500 |
PE |
170 |
|
GH4002 |
1.0mm×2 |
2.2×4.4±0.1 |
500 |
PE |
170 |
|
GHV4001 |
1.0mm×1 |
2.2±0.07 |
500 |
PVC |
170 |
|
GHV4002 |
1.0mm×2 |
2.2×4.3±0.1 |
500 |
PVC |
170 |
|
GHEV4001 |
1.0mm×1 |
5.0±0.2 |
500 |
PE/PVC |
170 |
|
GHEV4002 |
1.0mm×2 |
4.0×5.5±0.1 |
500 |
PE/PVC |
170 |
|
GHN4001 |
1.0mm×1 |
2.2±0.07 |
500 |
NYLON |
170 |
|
GHCP4001 |
1.0mm×1 |
2.2±0.07 |
500 |
CHLORINATED |
170 |
|
GHCP4002 |
1.0mm×2 |
2.2×4.3±0.1 |
500 |
PE |
170 |
|
GHTT4001 |
1.0mm×1 |
5.0±0.2 |
500 |
PE/PVC |
170 |
|
GHTT4002 |
1.0mm×2 |
6.0±0.2 |
400 |
PE/PVC |
170 |
|
BH-2001 |
0.5mm×1 |
1.0±0.05 |
1000 |
Crosslinked |
250 |
|
BH-4001 |
1.0mm×1 |
2.2±0.07 |
500 |
PE |
200 |
|
LH-2001 |
0.5mm(151cores) |
1.0±0.05 |
1000 |
PE |
400 |
|
LH-4001 |
1.0mm(151cores) |
2.2±0.07 |
1000 |
PE |
400 |
|
LH-4001-1.3 |
1.0mm(151cores) |
1.3±0.05 |
1000 |
PE |
400 |
Application characteristics of plastic optical fiber
- Light weight, good toughness, strong earthquake resistance and crack resistance, durable and reliable
- No electromagnetic wave radiation, no influence of electric noise, strong anti-interference ability
- Low maintenance cost, saving copper resources, low carbon energy saving and environmental protection
- Simple installation, no welding and cutting
- Good coupling and strong light guiding ability
- High bandwidth, high speed, high performance
- Good confidentiality, safety and reliability
- Waterproof, moisture-proof, magnetic-proof, lightning-proof, can meet the requirements of specific occasions
Application scope of communication plastic optical fiber
For fiber-to-the-home (FTTH)
Cooperating with quartz fiber, it is effective at the end of the broadband network. Plastic fiber is a good solution to solve the problem of "the last few hundred meters".
For consumer electronics
Plastic optical fiber is used in navigation equipment, in-car communication and on-board entertainment audio-visual systems, in-car TVs, DVD players, stereos, lamps, and digital switch sensor connection lines.
For automotive intelligence
Plastic optical fiber is used in navigation equipment, in-car communication and on-board entertainment audio-visual systems, in-car TVs, DVD players, stereos, lamps, and digital switch sensor connection lines.
For industrial control and monitoring systems
Plastic optical fiber can be used for control lines in strong magnetic fields of power plants and substations, equipment and equipment connection in industrial control, information connection of sensors, changes in detection targets, and transmission of network image information.
For military communications
It is widely used in battlefield mobile networks, military command systems, chariots, fighter planes, and warships' loading equipment. It will be difficult to replace its role in future electronic countermeasures.
